DePuy Synthes 271072 Titanium Reconstruction Plate

Condition: New
Part #: 271072

$528.00

SKU: 271072 Categories: ,
MAKE AN OFFER
Description

The DePuy Synthes 271072 is a sterile, single-use 3.5 mm reconstruction plate engineered for high-precision orthopedic fixation. Crafted from medical-grade titanium alloy, this 10-hole plate provides a critical balance of structural rigidity and anatomical contouring. It is specifically designed for complex reconstructive surgeries, acute fracture management, and the treatment of non-unions where stable internal fixation is paramount for osteogenesis.

By utilizing a low-profile geometry, the 271072 minimizes the risk of post-operative soft tissue irritation and hardware prominence, making it an excellent choice for regions with minimal soft tissue coverage.

Core Technology and Material Science

The foundation of the 271072 plate lies in its Titanium Alloy (Ti-6Al-4V) construction. Titanium is the gold standard for long-term orthopedic implants due to its unique properties:

  • Superior Biocompatibility: Minimizes immune response and promotes osseointegration.

  • Modulus of Elasticity: Titanium’s modulus is closer to human bone than stainless steel, reducing the “stress shielding” effect and encouraging natural bone loading.

  • Corrosion Resistance: Highly resistant to bodily fluids, ensuring long-term structural integrity.

  • MRI Compatibility: Titanium is non-ferromagnetic, allowing for safer post-operative diagnostic imaging compared to traditional steel implants.

Mechanism of Action

The DePuy Synthes 271072 functions through rigid internal fixation. The 10-hole configuration allows for multiple points of screw fixation, which serves two primary mechanical purposes:

  1. Neutralization: The plate acts as a bridge to protect the fracture site from torsional and shear forces.

  2. Compression: When used with dynamic compression techniques, the plate can exert axial pressure across the fracture line, accelerating primary bone healing.

  3. Anatomical Contouring: Despite its strength, the “reconstruction” design allows for easier intraoperative bending to match the specific bony morphology of the patient.

Clinical Applications and Indications

This plate is a versatile component of the DePuy Synthes 3.5 mm small fragment system. Primary indications include:

  • Complex Reconstructive Surgery: Restoration of bony alignment following tumor resection or congenital deformity correction.

  • Fracture Management: Fixation of small bone fractures in the upper extremities, pelvis, or clavicle.

  • Non-union/Mal-union Treatment: Stabilizing failed previous healings to provide a fresh environment for bone graft incorporation.

  • Small Bone Segments: The 10-hole length is optimized for segments that require more stability than a 6-hole plate but lack the space for full-length humeral or pelvic plates.

Key Advantages for Surgical Teams

  • Low-Profile Design: A 3.5 mm thickness reduces the physical footprint of the implant, decreasing the likelihood of patient discomfort and skin breakdown.

  • Optimized Hole Spacing: The 10-hole layout provides ample fixation options for varied screw trajectories, essential for bypassing poor-quality bone.

  • System Integration: Fully compatible with the 271071 series and standard 3.5 mm instrumentation, ensuring a seamless workflow without the need for specialized, one-off tools.

  • Sterile Delivery: Provided in sterile packaging to reduce the risk of surgical site infections (SSI) and eliminate the need for hospital-side pre-processing.

Technical Specifications

Feature Specification
Catalog Number 271072
Material Medical-Grade Titanium Alloy (Ti-6Al-4V)
System Size 3.5 mm
Number of Holes 10 Holes
Format Sterile, Single-Use
Compatibility 3.5 mm Cortex and Locking Screws; 271071 Series
Profile High Low-profile / Small Fragment

Frequently Asked Questions

What are the primary indications for the DePuy Synthes 271072 plate?

The 271072 is primarily indicated for orthopedic reconstruction, acute fracture fixation, and the management of non-unions. Its 10-hole, 3.5 mm design makes it particularly suitable for small bone segments in the upper extremities or pelvis where stable internal fixation and anatomical contouring are required for proper healing.

Why is titanium alloy preferred for the 271072 reconstruction plate?

Titanium alloy is chosen for its exceptional biocompatibility, high strength-to-weight ratio, and corrosion resistance. Crucially, its modulus of elasticity is closer to human bone than stainless steel, which helps reduce stress shielding. Additionally, its non-ferromagnetic properties make it more compatible with post-operative MRI and CT imaging.

Is the DePuy Synthes 271072 plate provided sterile?

Yes, the DePuy Synthes 271072 is supplied as a sterile, single-use implant. This ensures maximum patient safety by reducing the risk of cross-contamination and surgical site infections. It also streamlines the surgical workflow by eliminating the need for in-house sterilization before the procedure can begin.

How does the low-profile design benefit the patient post-operatively?

The 3.5 mm low-profile design is engineered to minimize the “bulk” of the implant under the skin. This is critical in areas with thin soft tissue coverage, as it reduces hardware prominence, decreases the risk of soft tissue irritation, and improves the overall aesthetic and functional outcome for the patient.

What screw sizes are compatible with the 271072 10-hole plate?

This plate is part of the 3.5 mm small fragment system. It is designed to be used with standard 3.5 mm cortex screws and, depending on the specific plate iteration, may also support locking screws. It integrates seamlessly with the 271071 series instrumentation for efficient and reliable surgical fixation.

Can the 271072 plate be contoured during surgery?

Yes, as a “reconstruction” plate, it is specifically designed to allow for intraoperative bending and contouring. This allows the surgeon to shape the plate to the unique anatomical dimensions of the patient’s bone, providing a more precise fit and better stability across complex fracture sites or reconstructive areas.
